● Product Description
T8 LED Integrated Tube is a cutting-edge LED lighting solution engineered for modern indoor lighting applications. This integrated LED tube incorporates a durable aluminum housing and premium PC diffuser that delivers high luminous efficacy of 110–130 lm/W and a long lifespan of up to 50,000 hours, significantly reducing energy consumption and maintenance needs compared to traditional fluorescent lighting.
With excellent color rendering and multiple color temperature options (3000K, 4000K, 5000K, 5700K, 6000K), this LED tube ensures bright, consistent light that enhances visibility and comfort in workspaces. Its patented male-female linkable design allows fixtures to be connected in series without dark spots, creating clean, continuous illumination across long runs. This linkable system supports configurations up to 600 W, offering flexibility in lighting large commercial or industrial areas.
The integrated design eliminates the need for external drivers or complicated wiring, allowing for quick plug-and-play installation. Certified by ETL, TUV, RCM and CE,this lighting option meets rigorous safety and performance standards while delivering reliable, high-quality illumination for a variety of indoor lighting needs.
| Technical Specifications | |
| Input Voltage | AC100-277V 50/60Hz |
| Total harmonic distortion | THD<19% |
| Power Factor | PF>0.95 |
| Efficiency | 110-130LM/W |
| Color Index | Ra>82 |
| Switching Time | 100,000 |
| Lumen maintenance @6000h | >80% |
| Operation Temperature | -20°C ~ +50°C |
| Finish | Silver |
| Life Span | 50,000 hours |
| CCT | 3000K,4000K,5000K,6000K |
| Material | Aluminum + PC |

● Features
● Patent Male-female T8 led tube linkable design
● Seamless & No Dark in-line connection
● ETL TUV RCM CE RoHs approved, DLC Listed
● Maximum tandem wattage: 200W and 600W optional
● Enjoy Hassle-free, safe and easy Installation
● Applications
T8 LED Integrated Tube Light is ideal for a wide range of indoor lighting environments, including:
● Warehouse aisles and storage facilities
● Industrial factories and workshops
● Retail shops, supermarkets and malls
● Office spaces and meeting rooms
● Basements, tunnels, stairwells
● Industrial factories and workshops
● Cold storage and food storage areas
● Hotels, schools and public buildings

| Integrated T8 LED Fixture Specifications | |||||||
| Model | Length | Power | CCT | Cover | Led type | Lumens (lm) ±10% | Package |
| LY-T8DL600-9W | 2ft/600mm | 9W | 3000K 4000K 5000K 5700K 6000K |
Frosted Clear |
SMD2835 | 990 - 1080 | 725*240*205 (mm) 20pcs/ctn |
| LY-T8DL900-13W | 3ft/900mm | 13W | SMD2835 | 1430 - 1560 | 1035*240*205 (mm) 20pcs/ctn | ||
| LY-T8DL1200-18W | 4ft/1200mm | 18W | SMD2835 | 1980 - 2160 | 1335*240*205 (mm) 20pcs/ctn | ||
| LY-T8DL1200-22W | 4ft/1200mm | 22W | SMD2835 | 2420 - 2640 | 1335*240*205 (mm) 20pcs/ctn | ||
| LY-T8DL1500-25W | 5ft/1500mm | 25W | SMD2835 | 2750 - 3000 | 1640*240*205 (mm) 20pcs/ctn | ||
| LY-T8DL1800-28W | 6ft/1800mm | 28W | SMD2835 | 3080 - 3360 | 1900*240*205 (mm) 20pcs/ctn | ||
| LY-T8DL2400-44W | 8ft/2400mm | 44W | SMD2835 | 4840 - 5280 | 2510*150*166 (mm) 9pcs/ctn | ||
● Options
● Fuctions: Standard Version / Triac Dimmable Version / 0-10V dimming Version/ ON-OFF Swith
● Connection Way: Lead in wire / M-F Connection / Power cord with Plug
● Installation Type : T8 Standard Clip / Magnetic Clip / Suspending Kits
● Cover: Milky / Clear
● Product Line Drawing (Size:mm) ● Light Distribution Curve

One 250mm power cord, one 250mm connection cable, one small connector, clips and screws...
(Length for power cord or connection cable can be customized for this T8 Integrated Tube Light)

● Installation
● To avoid electric shock, maintenance and installation should only be carried out by a professional electrician
● Please use it under correct input power range
● Do not use in the outdoor environment
● Before installation, turn off the power to make sure safety
● Follow the diagram below for proper installation

● FAQs – Frequently Asked Questions
Q1: Can the LONYUNG T8 LED Integrated Tube replace traditional fluorescent T8 tubes?
A: Yes. This integrated LED tube is designed as a direct, energy-efficient replacement for traditional fluorescent T8 fixtures with better performance and longer life.
Q2: What color temperature options are available?
A: It offers multiple color temperatures – 3000K (warm white), 4000K (neutral white), 5000K (natural white), and 6000K (daylight white) to suit different lighting needs.
Q3: How does the linkable design work?
A: Male-female linkable design allows multiple LED tubes to be connected in series without dark areas, enabling seamless continuous lighting installations up to 600 W.
Q4: Is this tube suitable for industrial and commercial lighting?
A: Yes. It's high efficiency, long lifespan, and robust construction make it ideal for industrial environments such as warehouses and factories, as well as commercial spaces like retail stores.
Q5: What certifications ensure the product’s quality and safety?
A: Our T8 LED Integrated Tube is certified under ETL, TUV, RCM, CE and is DLC listed, confirming compliance with international performance, safety, and energy efficiency standards.
Q6: If you have five lights connected in a series circuit and one of them burns out, will the entire line would typically go out ?
A: Our T8 integrated tube lights are designed with a parallel-circuit connection, this means if one T8 tube fails, the other LED T8 lights will continue to operate normally.
● About Us - LONYUNG Lighting
Founded in 2010, LONYUNG Lighting has grown into a leading innovator in the commercial and industrial LED lighting industry. With a strong commitment to technology, design, and sustainability, we specialize in creating linear lights, LED linear high bay lights, and tri-proof lights that redefine lighting performance. Our manufacturing facility adheres to international standards, ensuring high-quality products trusted by global customers across retail, office, industrial, and warehouse applications.
